High-Efficiency Swivel Wheel Sorters--- Layout of the DWS system sorting line. 10sorting stations 1 NG sorting station.

High-efficiency swivel wheel sorter fits DWS system sorting line layout. Equipped with 10 sorting stations and 1 NG station. It features high efficiency and stable operation, ideal for automatic sorting of parcels and small goods in logistics and e-commerce warehouses.

Send Email：[email protected]

Email INQUIRY

Product details

High-Efficiency Swivel Wheel Sorters: 10 Sorting Stations + 1 NG Configuration

How DWS system integration enables intelligent, high-speed sorting for large-scale logistics operations in 2026

Figure 1: DWS system sorting line layout with 10 sorting stations and 1 NG station

The Challenge: Scaling Sorting Operations for High-Volume Logistics

As parcel volumes continue to grow exponentially in 2026, logistics operators face the critical challenge of processing 10,000+ items per hour while maintaining 99.9%+ accuracy. Traditional sorting systems often struggle with:

Critical Scaling Challenges:

Limited Throughput: Single-line systems cannot handle peak volumes during holiday seasons
High Error Rates: Manual sorting or basic automation leads to misrouted parcels
Inflexible Configuration: Fixed sorting layouts cannot adapt to changing operational needs
NG (No Read) Handling: Poor exception handling creates bottlenecks and manual re-sorting
Integration Complexity: Difficulty integrating with DWS (Dimensioning, Weighing, Scanning) systems

The Solution: 10-Station + 1 NG Swivel Wheel Sorter Configuration

The High-Efficiency Swivel Wheel Sorter with 10 Sorting Stations + 1 NG Station is a premium intelligent sorting solution designed for high-volume logistics operations. Integrated with DWS (Dimensioning, Weighing, Scanning) systems, this configuration delivers:

Feature	Specification	Operational Benefit
10 Sorting Stations	Configurable outlet positions	Route parcels to 10 different destinations based on ZIP code, carrier, or custom logic
1 NG (No Read) Station	Dedicated exception handling	Automatically route unreadable items for manual inspection, preventing line stops
DWS Integration	Dimensioning + Weighing + Scanning	Real-time parcel data for optimized routing and billing accuracy
Throughput Capacity	Up to 8,000 items/hour	Handle peak volumes without system overload
Sorting Accuracy	≥99.9%	Minimize misroutes and manual correction costs
Control System	PLC + SCADA + IoT	Centralized monitoring, predictive maintenance, remote diagnostics

Swivel Wheel Sorter DWS System Integration

Figure 2: DWS system integration with swivel wheel sorter for intelligent parcel routing

DWS System Integration: The Key to Intelligent Sorting

DWS (Dimensioning, Weighing, Scanning) integration is critical for modern logistics operations. Our swivel wheel sorter seamlessly integrates with DWS systems to enable:

DWS Integration Benefits:

Automatic Dimension Capture: Laser or infrared sensors measure parcel dimensions (L×W×H) in milliseconds
Precise Weight Measurement: Integrated scales capture weight data for shipping cost calculation
High-Speed Barcode Reading: Omnidirectional scanners read 1D/2D barcodes at speeds up to 3.5m/s
Real-Time Data Transmission: All DWS data transmitted to WMS/WCS for optimized routing
Shipping Cost Optimization: Accurate dimensional weight calculation prevents carrier billing disputes

NG (No Read) Station: Intelligent Exception Handling

One of the most critical aspects of a high-efficiency sorting system is how it handles exceptions. Our 1 NG (No Read) Station configuration ensures:

Exception Type	Cause	NG Station Handling
Unreadable Barcode	Damaged, obscured, or missing barcode	Route to NG station for manual scanning or manual key-entry
Oversized Parcel	Parcel exceeds dimension limits	Route to NG station for special handling or manual sorting
Underweight/Overweight	Weight outside expected range	Flag for manual inspection to prevent shipping errors
System Communication Error	WMS/WCS connection timeout	Temporary stop and route to NG for manual processing

Technical Specifications

Sorting Performance

Throughput: 6,000 - 8,000 items/hour
Accuracy: ≥99.9%
Sorting Stations: 10 + 1 NG
Parcel Size: 50×50×10mm to 600×500×400mm
Parcel Weight: 0.01kg - 30kg

DWS System Specs

Dimension Accuracy: ±5mm
Weight Accuracy: ±10g
Scanning Speed: Up to 3.5m/s
Barcode Types: 1D (Code 128, EAN, UPC), 2D (QR, DataMatrix)
Communication: TCP/IP, RS232, USB

Software & Integration

Compatible WMS/WCS Platforms:

SAP EWM

Manhattan WMS

Blue Yonder

Oracle WMS

Infor WMS

Custom WMS (API)

Frequently Asked Questions (FAQ)

What is the typical payback period for a 10-station swivel wheel sorter with DWS?

For operations processing 5,000+ parcels/day, the typical payback period is 18-24 months. Labor cost reduction (60-75%) and accuracy improvement (99.2% to 99.9%+) are the primary ROI drivers. DWS integration adds 6-12 months to payback but delivers significant shipping cost savings through accurate dimensional weight calculation.

Can the NG station be reconfigured as a regular sorting station later?

Yes! The modular design allows any station (including NG) to be reconfigured as a regular sorting station or vice versa. This flexibility is ideal for operations with evolving volume patterns or seasonal peaks. Reconfiguration typically takes 2-4 hours with minimal tools.

What is the maintenance requirement for the DWS system?

DWS systems require minimal maintenance: daily cleaning of scanning windows (5 minutes), weekly calibration check (15 minutes), and annual professional calibration. Our IoT connectivity enables remote diagnostics and predictive maintenance alerts, minimizing unplanned downtime.

How does the system handle parcels with multiple barcodes?

Our intelligent DWS system reads all visible barcodes and uses priority logic to select the correct one (typically the shipping label barcode). If multiple barcodes are detected, the system can be configured to route to NG station for manual verification or use AI-based logic to select the most likely correct barcode.

What training is required for operators?

Basic operation training takes 4 hours (classroom + hands-on). Advanced configuration and maintenance training takes 2 days. Our multilingual training materials (English, Spanish, Chinese, Arabic) and video tutorials ensure rapid onboarding. Remote training via video conference is also available.
