Belt Turning Machine | 30/45/90/180 Degree Belt Curve Conveyor for Logistics Sorting

Belt Turning Machine is a core steering device in automated conveying systems, designed to smoothly redirect materials at 30°/45°/90°/180° angles. It seamlessly connects straight conveyors, solves space layout constraints, and is widely used in logistics sorting, e-commerce warehousing, food & pharmaceutical, and electronics manufacturing industries.

Send Email：[email protected]

Email INQUIRY

Product details

BELT TURNING MACHINE

Professional Belt Curve Conveyor | 30deg/45deg/90deg/180deg Smooth Turning Solution

WINDA Belt Turning Machine -- Precision Steering for Smart Logistics

30deg-180deg

Turning Angles

500-1400

mm Belt Width

0.75-2.2 kW

Motor Power

VFD Speed

Variable Control

Product Overview

The Belt Turning Machine is an essential special steering conveyor in automated material handling production lines. It is commonly matched with straight belt conveyors, roller conveyors, sorting machines and other logistics equipment to realize smooth material diversion at angles of 30deg, 45deg, 90deg and 180deg according to on-site layout requirements.

This equipment perfectly connects the whole automatic production line, effectively solves the problems of limited workshop space and complicated route planning, and makes material transportation more flexible and efficient. With strong universality, it is suitable for cartons, parcels, turnover boxes, food gift boxes, electronic components, pharmaceutical packages and other light and regular goods. It is widely used in e-commerce warehousing, express distribution centers, food processing, pharmaceutical production, electronics manufacturing, home appliances, daily chemical and many other industries.

Core Features & Advantages

[+] Robust Steel Frame Structure

High-quality carbon steel integral welding frame with sandblasting and anti-rust plastic spraying treatment. Full stainless steel option available for food/pharmaceutical hygiene standards.

[+] Premium Conveyor Belt Options

Standard wear-resistant PVC belt. Optional food-grade PU belt, anti-static belt, anti-slip belt, oil-resistant and high-temperature resistant belt available.

[+] Variable Frequency Drive System

VFD motor with tapered turning rollers delivers high transmission efficiency and uniform power output. Conveying speed freely adjustable (0.1~1 m/s). Stable start/stop without impact.

[+] Professional Guiding Mechanism

Built-in guiding components and automatic tensioning devices compensate belt tension in real time, eliminating deviation, slack, abnormal noise and reducing failure rate.

[+] Low Noise & Material Protection

Precision machined and dynamically balanced transmission parts ensure low noise operation. Belt and guiding structure provide reliable protection against scratch and extrusion.

[+] Wide Customization Available

Customize turning angle, belt width, inner radius, conveying height, speed, frame material. Double-layer or multi-layer structure options for complex solutions.

Technical Specifications

Parameter	Specification
Turning Angle	30deg / 45deg / 90deg / 180deg (Custom angles available)
Conveying Speed	0.1 ~ 1 m/s (Variable frequency speed regulation)
Standard Belt Width	500mm / 800mm / 1000mm / 1200mm / 1400mm
Inner Turning Radius	1270mm ~ 2200mm (Optional)
Motor Power	0.75kW ~ 2.2kW
Frame Material	Carbon steel with plastic spray (Standard) / 304 Stainless steel (Optional)
Belt Material	PVC (Standard) / PU / Anti-static / Food-grade (Optional)
Operation Mode	Continuous / Intermittent \| Single or Multi-layer structure

Top view of WINDA Belt Turning Machine showing precision curved design

Application Scenarios

E-commerce Warehousing

Parcel sorting, carton conveying, matched with automated sorting systems for high-throughput distribution centers.

Food & Beverage Industry

Finished product and package transport with food-grade PU belt option, fully compliant with HACCP requirements.

Pharmaceutical Manufacturing

Cleanroom-compatible stainless steel model for medicine boxes and sterile material delivery.

Electronics Assembly

Anti-static belt configuration protects precision electronic components from ESD damage during conveying.

Daily Chemical & Light Industry

Automatic circulation of boxed and bagged finished goods in cosmetics, toiletries and household products.

Airport Cargo Handling

Baggage check-in systems and baggage reclaim carousels requiring reliable curved conveying.

Why Choose WINDA?

Factory Direct Sales

No middlemen, competitive pricing

Custom Engineering

Tailored to your layout needs

Quality Certified

CE certified, ISO9001 factory

Fast Support

24hr response, global shipping

Frequently Asked Questions

Q1: What is a belt turning machine?

A belt turning machine (also called a belt curve conveyor or corner turning conveyor) is a specialized steering conveyor that smoothly redirects materials at specific angles (typically 30deg, 45deg, 90deg or 180deg) within automated production lines. It connects straight conveyors and optimizes space utilization in logistics facilities.

Q2: What is the difference between a belt turn and a roller curve?

A belt turn uses a continuous flat belt surface that provides stable support for items of various sizes and shapes, ideal for cartons, boxes and soft packages. Roller curves use individual tapered rollers which are better for rigid items but may cause smaller items to slip between rollers. Belt turns offer smoother, quieter operation with better item protection.

Q3: What belt widths are available?

Standard belt widths are 500mm, 800mm, 1000mm, 1200mm and 1400mm. Custom widths can be manufactured according to your specific application requirements. The inner turning radius ranges from 1270mm to 2200mm depending on belt width and turning angle.

Q4: Can it be used in food industry?

Yes! For food and pharmaceutical applications we offer full 304 stainless steel frame construction combined with food-grade PU belts. These configurations meet HACCP hygiene standards and are easy to clean and sanitize, making them suitable for clean room environments.

Q5: How is the speed controlled?

The machine uses a variable frequency drive (VFD) system allowing speed adjustment from 0.1 m/s to 1 m/s. This enables seamless integration with upstream and downstream equipment operating at different speeds. The VFD also provides soft start/stop functionality to prevent material tipping during acceleration and deceleration.

Q6: What is the lead time and warranty?

Standard models ship within 15-25 working days after order confirmation. Custom designs may require 30-45 days depending on complexity. All machines come with a 1-year comprehensive warranty covering parts and workmanship. We provide lifetime technical support and spare parts availability for all our belt turning machines.

Ready to Optimize Your Production Line Layout?

Get a free custom solution quote from WINDA's engineering team today.

Email Us Now WhatsApp Us
